THDB23 – 23k Tandem Dual Deckover Hydraulic Tilt Trailer

Trailers > Tilt Trailers > I-Beam Frame Deckover Hydraulic Tilt Trailer > THDB23 – 23k Tandem Dual Deckover Hydraulic Tilt Trailer

GVWR
Length
Width
Payload Capacity
Deck Load Angle

23,000 lbs.
24', 26', 28', 30'
102"
15,800 - 19,690 lbs.
16°

Find a Dealer Download Brochure

Base Specs
Standard Features
Options

Length
Weight
24'
6,300 lbs
26'
6,600 lbs
28'
6,900 lbs
30'
7,200 lbs

Deck Width 102"

Deck Height 35"

Frame 10" I Beam Frame

Crossmember 3" Channel

Flooring DURA Color Pressure Treated

Axles 2 - 10,000 lb. Premium Axles

Suspension 5-Leaf Slipper

Brakes Electric Self Adjusting Brakes

Tires ST235/80R16 10 ply Radial

Wheel 16" Black Dual Wheels

Coupler 3" Pintle Coupler

Jack Dual 10K Hydraulic Hyjacker

Stake Pockets Stake Pockets w/ Rub Rail

Battery GR27 Deep Cycle

Wiring Harness All-Weather Wiring Harness (7-way RV)

Charge Wire Charge Wire with Circuit Breaker

Lighting Rubber Mount Lifetime LED Lights

• Blackwood Decking

• D Rings

• Electric/Hydraulic Brakes

• G ply Tire Upgrade

• Gooseneck

• Spare Tire

• Spare Tire Mount

• Underbody Tool Box (24"

• 36"

• 48")

• Winch Mount Plate

• Wireless Remote

A Closer Look

Charge Up with the 110V Charger

Don't get stranded without battery power to operate your trailer's lift! This included 5 Amp, 110V Charger provides you a fast and efficient way to charge your trailer's battery, so you always have the power to get the job done.

A Closer Look

Dual Hydraulic Jacks

For easy and convenient hookup and unhitch, our BWise manufactured hydraulic jack system gives the added benefit of both saving your time and energy to get your trailer prepped for hitching or unhitching to your tow vehicle. Allow for more spread of the load on the ground, more stability for heavier trailer loads, plus the convenience of a push button, no cranking setup. BWise hydraulic jacks are designed specifically for our trailers, so you know you're getting the right equipment for your trailer.

A Closer Look

I-Beam Frame

I-Beam frames are an engineered frame design that allows you to handle higher payloads on a trailer without a substantial increase in trailer manufacturing weight. These frames handle stress more efficiently across their design, giving more stability and a better weight to strength ratio. With an integrated tongue, trailers built with an I-Beam frame are built for your heavy-hauls.

A Closer Look

Stake Pockets with Rub Rail (EHD Series)

Get more capability from your trailer by taking advantage of the included stake pockets plus rub rail for added tie-down points for your cargo. Stake pockets also provide the added benefit of building up a sidewall to help keep cargo contained. At the same time, the rub rail protects your trailer from forklifts and other equipment while sideloading up your trailer.
